  Coupler Type ST (TSF)

  odel	Dimensions (mm)
  	Ls	DÆ	Hp	A	T
  1TSF	25	17.5	6Hex.14×16.2	9	1/8-28PT
  2TSF	32	24	6Hex.19×21.9	13	1/4-19PT
  3TSF	35	28	6Hex.23×26.6	13	3/8-19PT
  4TSF	42	35	6Hex.29×33.5	17	1/2-14PT
  6TSF	48	45	6Hex.38×43.9	19	3/4-14PT
  8TSF	59	58	6Hex.50×57.7	22	1-11PT
  10TSF	64	69	62Æx2Hex.54	25	1.1/4-11pt
  12TSF	71	76	66Æx2Hex.58	25	1.1/2-11pt
  16TSF	80	95	82Æx2Hex.77	29	2-11pt

  Get Best Price
•

  Coupler Type ST (TPH)

  odel	Dimensions (mm)
  	Lp	C	HpÆ	A	TÆ	BpÆ
  1TPH	41	15.5	12	20	6.5	3
  2TPH	53	18	14	29	8	5
  3TPH	60	21	18	32	11	7
  4TPH	70	24	22	39	15	10
  6TPH	84	28	28	48	21	15
  8TPH	105	36	42	57	27	19
  10TPH	121	39	48	70	34.5	26
  12TPH	132	45	55	75	41	32
  16TPH	142	51	70	80	54	40

  Get Best Price
•

  Coupler Type SC (PH)

  DIMENSIONS
  Model	Dimensions (mm)
  	Lp	C	HpÆ	A	TÆ	BpÆ
  20 PH	57	20	16	30	9	7.5
  30 PH	61	20	16	34	11.3	7.5
  40 PH	65	20	20	38	15	7.5
  400 PH	66	23	22	36	15	13
  600 PH	77	23	30	45	21	13

  Get Best Price
•

  Coupler Type SC (SF)

  Model	Dimensions (mm)
  	Lp	DÆ	Hs	A	T
  20 SF	49.5	25.4	6Hex.19×21.9	13	1/4-19PT
  30 SF	50.5	25.4	6Hex.21×24.2	14	3/8-19PT
  40 SF	52.5	25.4	6Hex.29×33.3	15	1/2-14PT
  400 SF	57	35	6Hex.29×33.3	15	1/2-14PT
  600 SF	61	35	6Hex.35×40.4	17	3/4-14PT

  Get Best Price
