Star Knobs
| . | DIMENSION | PLASTIC THREAD | BRASS INSERT THREAD | M.S.STUD THREAD |
||||||||||
| D | H | d1 | 5/16″ | 3/8″ | 1/2″ | 5/8″ | 5/16″ | 3/8″ | 1/2″ | 5/8″ | 5/16″ | 3/8″ | 1/2″ | |
| S 1 | 25 | 36 | 18 | 08 | 06 | 05 | 06 | |||||||
| S 2 | 37 | 3928 | 20 | 08 | 10 | 08 | 10 | 08 | 10 | |||||
| S 3 | 50 | 4235 | 22 | 10 | 12 | 10 | 12 | 10 | 12 | |||||
| S 4 | 57 | 27 | 27 | 10 | 12 | 10 | 12 | 10 | 12 | |||||
| S 5 | 70 | 39 | 25 | 12 | 16 | 12 | 16 | 12 | ||||||
| S 6 | 60 | 51 | 38 | 10 | 12 | 16 | ||||||||
