Related products

•

  Manual Grease Pump

  MODEL	LGP-50
  	Reservoir Capacity	5 Kg
  	Discharge Per Stroke	10 gm
  	Maximum Pressure	120 Kg/sq.cm.

  Get Best Price
•

  Deluxe Lurication Units

  MODEL	LDU-03 S/ST	LDU-03 FS/FPS
  Reservoir Capacity	3 Litres	3 Litres
  Discharge Of Pump	0.5 LPM	0.5 LP
  Motor	1Æ , 120W, 230V	3Æ , 0.12 Kw, 415V
  Relief Valve Setting	13 kg/Cm2	13 kg/Cm2
  Pressure Switch Setting	—-	—-
  Float Switch	220V, 1 Amp. Max (Single Phase}	220V, 1 Amp. Max

  Get Best Price
•

  Hand Operated Single Shot 2

  MODEL	RESERVOIR CAPACITY (IN CC)	DISCHARGE PER STROKE (IN CC)	MOUNTING BOLT USED
  	HCL-M	250	4	M6X75-2Nos.
  	HCL-4	400	4	M6X90-4Nos.
  	HCL-8	800	8	M6X100-4Nos.
  	HCL	1600	10	M6X125-4Nos.
  	HCL-M DX	250	4	M8X30-4Nos.
  	HCL-4 DX	400	4	M8X30-4Nos.
  	HCL- 8 DX	800	8	M8X30-4Nos.

  Get Best Price
•

  Junction Blocks

  ODEL	LENGTH (L)	CENTRE (C)	THREAD(T)	.	MODEL	LENGTH (L)	CENTRE (C)	THREAD(T)
  JB1	51	37	M8X1-5/16UNF		JB8	165	151	M8X1-5/16UNF
  JB2	51	37	M8X1-5/16UNF		JB1(3)	65	50	M10X1-1/8BSP
  JB3	70	56	M8X1-5/16UNF		JB2(3)	65	50	M10X1-1/8BSP
  JB4	89	75	M8X1-5/16UNF		JB3(3)	90	75	M10X1-1/8BSP
  JB5	108	94	M8X1-5/16UNF		JB4(3)	115	100	M10X1-1/8BSP
  JB6	127	113	M8X1-5/16UNF		JB5(3)	140	125	M10X1-1/8BSP
  JB7	146	132	M8X1-5/16UNF		JB6(3)	165	150	M10X1-1/8BSP

  Get Best Price
